Frame:
Alloy Frame / Virtual 4 link kinematic VLK 27.5´´ and 29´´ compatible / geo adj. / Boost 148x12mm 140mm travel / Bosch Gen4 / Integr. removable Battery Tapered Headtube E2 Central Kickstand Mount Range Booster Ready
Fork:
Marzocchi Z2 Air / eMTB+ Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer 44mm offset / Reb. Adj. / Lockout / 140mm travel
Fork travel: 140 mm
Shock:
X-Fusion NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 140-90-Lockout / 185x50mm
shock Travel: 140 mm
Rear derailleur:
SRAM NX Eagle / 12 Speed
Shift lever:
SRAM SX Eagle Single Click
Number of gears:
12
Sprocket:
SRAM PG1210 / 11-50 T
Crankset:
FSA CK-320 / 165mm / 34T
Front brakes:
SRAM DB8 4 Piston Disc
Rear brakes:
SRAM DB8 4 Piston Disc
Front brake disc:
Centerline CL rotor 200mm Rear
brake disc: Centerline CL rotor 200mm
Rims:
Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready
Front hub:
Formula CL-811 / 15x110mm
Rear hub:
Formula CL-148S / Boost 148x12mm
Spokes:
Stainless Black
Front tires:
Maxxis Rekon / 29x2.6´´ / 60TPI Wire Bead EXO Dual
Rear tires:
Maxxis Rekon / 29x2.6´´ / 60TPI Wire Bead EXO Dual
Headset:
Syncros ER2.0 Press Fit E2 / Tapered 1.5´´-1 1/8´´ OD 52/62mm / ID 44/56mm
Handlebar:
Syncros Hixon 2.0 Rise / Alloy 6061D.B. 20mm rise / 8° / 740mm
Stem:
Syncros FL2.0 / 6061 Alloy L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8´´
Grips:
Syncros Comfort lock-on grips
Saddle:
Syncros Capilano
Seatpost:
Syncros Duncan Dropper Post 2.5 31.6mm / S size 100mm / M size 125mm / L size 150mm
Motor:
Bosch Performance CX EU: 25kmh / INT: 20mph
Battery:
PowerTube 500Wh
Battery capacity:
500 Wh
Charger:
PowerTube 500Wh
Display:
Bosch Purion
Handlebar remote:
SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 modes
Weight:
234 kg
