Frame
Spark RC Carbon HMF
Integrated Suspension Technology
Flex Pivot, Adjustable head angle
Syncros Cable Integration System
BB92, UDH Interface, 12x148mm with 55mm Chainline

Fork
FOX 32 Float Rhythm Grip
3-Modes, Kabolt 15x110mm axle, 44mm offset, tapered steerer
Reb. Adj., Lockout, 120mm travel

Rear Shock
FOX Float LV Custom EVOL Performace Trunnion
3 modes, Lockout-Trail-Descend
DPS, Reb. Adj.
Travel 120mm, T165X45mm

Remote System
SCOTT TwinLoc Technology
Suspension & Dropper Remote
3 Suspension modes

Rear Derailleur
SRAM Eagle 70 Transmission 12 Speed

Shifters
SRAM Eagle 70 Trigger

Crankset
SRAM Eagle 70 Transmission
DUB, 55mm CL, 34T

Chainguide
SCOTT custom

BB-Set
SRAM DUB PF 92 MTB Wide, shell 41x92mm

Chain
SRAM CN Eagle 70 Transmission

Cassette
SRAM Eagle XS 1270 V2 Transmission 10-52

Brakes
SRAM DB4 4-Piston Disc

Rotor
SRAM Centerline CL Rotors 180/F and 160/R

Handlebar
Syncros Fraser 2.0 XC Alloy 6061 D.B.
Flat Bar, 8°, 740mm, Syncros Performance XC lock-on grips

H'stem
Syncros XC 2.0
Syncros Cable Integration System
-12° rise, 6061 Alloy, 31.8mm, 1 1/8"

Seatpost
Syncros Duncan Dropper 1.5XC, 31.6mm, all sizes 100mm

Seat
Syncros Belcarra V2.0 Cut Out
CRMO rails

Headset
Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB

Hub (Front)
Formula CL-811, 15x110mm

Hub (Rear)
Formula CL-148S, 12x148mm
Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools

Spokes
Stainless Black 15G, 1.8mm

Rims
Syncros X-30SE, 32H, 30mm
Tubeless ready

Front Tire
Maxxis Rekon Race, 29x2.4", 120TPI Foldable Bead
Tubeless Ready, EXO

Rear Tire
Maxxis Rekon Race, 29x2.4", 120TPI Foldable Bead
Tubeless Ready, EXO

Approx weight in KG
12.8 (Tubless setup)

Approx weight in LBS
28.22 (Tubless setup)

Max. System Weight
130kg
