Frame
Carbon Frame, Integrated Suspension Technology Virtual 4 Link kinematic, Adjustable head angle Syncros Cable Integration System Bosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready
-
Travel
Front: 170mm, Rear: 150mm
-
Fork
RockShox ZEB Ultimate Air, E-Bike, Charger 3.1, HSC - LSC, Reb Adj., ButterCups, 15x110mm axle 44mm offset, tapered steerer, 170mm travel
-
Rear Shock
RockShox SuperDeluxe Ultimate, DebonAir Linear, Trunnion, RC2T, Reb Adj., T185X55mm
-
Drive Unit
EU: 25kmh, INT: 20mph Bosch Performance Line CX (BDU384Y)
-
Battery
PowerTube 800Wh
-
Display
Bosch Kiox 400C, Mini Remote
-
Charger
4A Charger
-
Rear Derailleur
SRAM GX Eagle AXS Transmission 12 Speed Wireless Electronic Shift System
-
Shifters
SRAM AXS Rocker Pod Controller
-
Crankset
SRAM GX Eagle, Alloy
-
Chainguide
e*thirteen, e*spec Slider
-
Chainring
SRAM Eagle Transmission 34T chainring
-
Chain
SRAM CN GX Eagle Transmission
-
Cassette
SRAM GX Eagle XS 1275 Transmission 10-52
-
Brakes
Shimano XT BR-M8220 4 Piston, Bosch ABS Pro
-
Rotor
Front: SM-RT66 220mm, Rear: SM-RT66 203mm
-
Handlebar
back sweep 8°, 780mm Syncros Hixon iC Carbon, Size S & M 15mm rise, Size L & XL 25mm rise Syncros Endurance lock-on grips
-
Seatpost
S size 140mm, M size 180mm, L size 180mm, XL size 210mm Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mm
-
Seat
Syncros Tofino-E 1.5 Regular Titanium rails
-
Headset
Stainless, +-0.6° head angle adjustment Syncros - Acros Angle adjust & Cable Routing HS System ZS56/28.6 – ZS56/40 MTB
-
Wheelset
Syncros Revelstoke-HD 1.5 IS F: 15x110mm, R: 12x148mm Boost 30mm Tubeless ready rim 28H Syncros Axle w/Removable Lever with Tool
-
Front Tire
Schwalbe Magic Mary 29x2.5", Gravity, Radial, Ultra Soft, Tubeless ready 120TPI Foldable Bead
-
Rear Tire
Schwalbe Albert 29x2.5", Gravity, Radial, Soft, Tubeless ready 120TPI Foldable Bead
-
Lights
Front Light Cable pre-installed Syncros integrated rear fender light
-
Approx weight in KG
24.3
-
Approx weight in LBS
53.57
-
Max. System Weight
130kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
