| Specification |
Detail |
| Frame |
Spark RC Carbon HMF, Flex Pivot, Adjustable Head Angle, BB92, UDH, 12x148mm |
| Fork |
RockShox SID Select 3P Air, Charger RL Damper, 120mm Travel, 15x110mm |
| Rear Shock |
RockShox NUDE 5 RL3 Trunnion, SCOTT Custom, 120-80mm Travel, T165x45mm |
| Remote System |
SCOTT TwinLoc 3-Mode Remote Suspension System |
| Rear Derailleur |
SRAM GX Eagle AXS Transmission, 12-Speed Wireless |
| Shifters |
SRAM AXS Pod Controller |
| Crankset |
SRAM GX Eagle Transmission, DUB, 34T, 55mm Chainline |
| Chainguide |
SCOTT Custom |
| Bottom Bracket |
SRAM DUB PF92 MTB Wide, 41x92mm Shell |
| Chain |
SRAM GX Eagle Transmission |
| Cassette |
SRAM GX Eagle XS-1275 Transmission, 10-52T |
| Brakes |
SRAM Level Bronze Stealth 4-Piston |
| Rotors |
SRAM HS2 Centerlock, 180mm Front / 160mm Rear |
| Handlebar |
Syncros Fraser iC SL XC Carbon, -12° Rise, 740mm |
| Grips |
Syncros Performance XC Lock-On |
| Seatpost |
Syncros Duncan Dropper 1.5XC, 100mm Travel, 31.6mm |
| Saddle |
Syncros Belcarra Regular 1.5, Titanium Rails |
| Headset |
Syncros - Acros Angle Adjust & Cable Routing, ZS56/28.6 – ZS56/40, ±0.6° |
| Wheelset |
Syncros Silverton 2.0-30 CL, 30mm Tubeless Ready, 28H, XD Driver |
| Front Tire |
Maxxis Rekon Race 29x2.4", EXO, 120 TPI, Tubeless Ready |
| Rear Tire |
Maxxis Rekon Race 29x2.4", EXO, 120 TPI, Tubeless Ready |
| Extras |
SRAM AXS Powerpack, Transport Axle, Syncros Axle w/ Tool (T25, T30, 6mm) |
| Approx. Weight |
11.8 kg / 26.01 lbs (Tubeless Setup) |
