Frame:
Alloy Frame with Virtual 4-link kinematic VLK. It's compatible with both 27.5" and 29" wheels and features geo adjustment. Boost 148x12mm spacing and 150mm of travel. Designed for Bosch Gen4 integration with a removable battery, Tapered Headtube E2/Forkstop, Central Kickstand Mount, and Range Booster Ready.
Fork:
RockShox 35 Silver TK Air. Features include a 15x110mm QR axle, Tapered Steerer, Rebound Adjustment, 2 Modes, Lockout, and 160mm travel. E-Bike specific.
Rear Shock:
X-Fusion NUDE Trunnion, SCOTT custom with travel/geo adjustment. Offers 3 modes: Lockout, Traction Control, and Descend. Also features Rebound Adjustment. Travel options are 150-100-Lockout, with dimensions of 185x55mm.
Travel:
Front: 160mm
Rear: 150mm
Remote System:
SCOTT TwinLoc Suspension System, providing 3 modes for both front and rear suspension, with an integrated grip clamp.
Drive Unit:
Bosch Performance CX
Battery:
PowerTube 625Wh
Display:
Bosch Purion
Charger:
4A Charger
Rear Derailleur:
SRAM NX Eagle / 12 Speed
Shifters:
SRAM SX Eagle Single Click
Crankset:
FSA CK-745 165mm / 34T
Chain Guide:
SCOTT Custom
Chainring:
SRAM Eagle 34T DM / Steel
Chain:
SRAM SX Eagle
Cassette:
SRAM PG1210 / 11-50T
Brakes:
Shimano BR-MT520 4 Piston
Rotors:
Front: SM-RT64 CL 203mm
Rear: RT-EM600 CL 203mm
Handlebar:
Syncros Hixon 2.0 / Alloy 6061D.B., 12mm rise / 9° / 760mm. Includes Syncros Women Pro lock-on grips.
Stem:
Syncros FL2.0 / 6061 Alloy, L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
Seatpost:
Syncros Duncan Dropper Post 2.5, 31.6mm.
S size: 100mm
M size: 125mm
L size: 150mm
Seat:
Syncros Savona 2.0 V-Concept
Headset:
Acros Blocklock / Tapered 1.5"-1 1/8", OD 52/62mm / ID 44/56mm
Hub (Front):
Formula CL-811 / 15x110mm
Hub (Rear):
Formula CL-148S / Boost 148x12mm
Spokes:
Stainless Black
Rims:
Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
Front Tire:
Schwalbe MagicMary 29x2.6", Snake Skin / TL-Easy / SuperTrail / Addix Soft
Rear Tire:
Schwalbe Hans Dampf 29x2.6", Snake Skin / TL-Easy / SuperTrail / Addix Speedgrip
Approx. Weight (KG):
24.9
Approx. Weight (LBS):
54.9
Max. System Weight:
128 kg
