| Frame |
Scale Alloy 6061 Custom Butted Tubing, Syncros Cable Integration System, BB92, UDH Interface, 12x148mm with 55mm Chainline |
| Fork |
RockShox Judy Silver TK Solo Air, 15x110mm QR axle, 51mm offset, Tapered Steerer, Reb. Adj., Lockout, 110mm travel |
| Front Travel |
110 |
| Rear Derailleur |
Shimano Deore RD-M6100 SGS, Shadow Plus, 12 Speed |
| Shift Levers |
Shimano Deore SL-M6100-R, Rapidfire Plus |
| Number of Gears |
12 |
| Front Brake |
Shimano MT200 Disc Brake |
| Rear Brake |
Shimano MT200 Disc Brake |
| Brake Disc Front |
Shimano SM-RT10 CL, 180mm |
| Brake Disc Rear |
Shimano SM-RT10 CL, 160mm |
| Front Rim |
Alex X-25/ 32H, 25mm, Tubeless ready |
| Rear Rim |
Alex X-25/ 32H, 25mm, Tubeless ready |
| Front Tire |
Maxxis Rekon Race, 29x2.4", EXO, Tubeless Ready |
| Rear Tire |
Maxxis Rekon Race, 29x2.4", EXO, Tubeless Ready |
| Front Hub |
Formula CL-811, 15x110mm |
| Rear Hub |
Formula CL-548M, 12x148mm, Micro Spline |
| Spokes |
Stainless Black 15G, 1.8mm |
| Handlebar |
12 |
| Handlebar Width |
740 |
| Stem |
Syncros Alloy 6061, oversized 31.8mm, 1 1/8", 6° angle |
| Stem Angle |
6 |
| Headset |
Syncros - Acros OE Cable Routing HS System, OD 50/62mm, ID 42/56mm |
| Grips |
Syncros Performance XC lock-on grips |
| Remote Lockout |
RockShox PopLoc Remote |
| Saddle |
Syncros Belcarra Regular 2.5 |
| Seatpost |
Syncros Duncan Dropper, 31.6mm, XS&S size 100mm, M size 130mm, L &XL size 150mm |
| Dropper travel |
100 |
| Crankset |
Shimano FC-MT512-1, 55mm CL, 32T |
| Bottom bracket |
Shimano BB-MT500, shell 41x92mm |
| Sprocket |
Shimano Deore CS-M6100-12, 10-51 T |
