| Frame |
Carbon CC |
| Frame shape |
Mountainbike |
| Material |
Carbon |
| Gender |
Unisex |
| Weight |
approx. 22.70 kg |
| permissible total weight |
130 kg |
| Fork |
Fox Podium Factory, Grip X2, 170mm |
| Damper |
Fox DHX2 Factory S: 400lb, M: 450lb, L: 500lb, XL: 550lb, XXL: 600lb |
| Manufacturer shift group |
Shimano |
| Rear derailleur |
Shimano Deore XT Di2 M8260, SGS, 12-speed |
| Number of gears |
1 x 12 |
| Circuit type |
Kettenschaltung |
| Crank handle |
e13 Helix Race Alloy e*spec All Sizes: 155mm |
| Cassette |
Shimamo XT M8200, 10–51t |
| Drive type |
Kettenantrieb |
| Freewheel/coaster |
Freilauf |
| Pedals included in the scope of delivery |
nein |
| Rims |
Reserve 30|HD Carbon |
| Hubs |
Front: DT Swiss 350, 20x110 Boost, 6-bolt, 28-hole; Rear: DT Swiss 350 DEG DF, 12x148, MicroSpline, 6-bolt, 32-hole |
| Wheel size |
27,5 Zoll / 29 Zoll |
| Tyres |
Front: Maxxis Assegai 29"x2.5", 3C MaxxGrip, Double Down; Rear: Maxxis Minion DHRII 27.5"x2.5", 3C MaxxTerra, Double Down |
| Motor manufacturer |
Bosch |
| Engine |
Bosch Performance CX |
| max. torque |
max. 120 Nm |
| Reach |
up to 150 km |
| Support for |
up to 25 km/h |
| Battery |
Bosch 600Wh PowerTube |
| Brakes |
SRAM Maven Silver |
| Handlebars |
OneUp Carbon Bar, 35mm: S: 760mm, 20mm rise; M–XXL: 800mm, 35mm rise |
| Seat post |
OneUp Dropper Post, 31.6 mm: 120 mm, M: 180 mm, L: 210 mm, XL–XXL: 240 mm |
| Saddle |
WTB Silverado Medium Fusion, Stainless |
| Stem |
Industry Nine A35 All Sizes: 40mm |
| Accessories/Miscellaneous |
Charger included |
