NSIDE LEG
44.5CM
FRAME
HAND BRUSHED AL6061, FORGED SLIDING DROP OUTS
FORK
HAND BRUSHED AL6061, FORGED DROP OUTS
STEERER TUBE
AL6061
CRANKS
CNC’D AL6061, 105MM
PEDALS
RESIN PLATFORM, SEALED CARTRIDGE BEARING
BOTTOM BRACKET
ER EXTERNAL CUP, SEALED CARTRIDGE BEARING
RIMS
16 x 20H, DOUBLE WALLED AL6061
REAR HUB
FOUR-BEARING CASSETTE FREE HUB, CNC’D AL6061
FRONT HUB
CARTRIDGE BEARING, CNC’D AL6061
AXLES
AL6061
BELT
GATES POWERGRIP 840-8M
FRONT SPROCKET
CNC’D AL6061, 46T, AL6061 AXLE
WEIGHT
5.95KGS WITHOUT PEDALS
REAR SPROCKET
CNC’D AL6061, 22T
BRAKES
TEKTRO 837AL, 102MM ARMS
LEVERS
TEKTRO SHORT REACH JL352
FRONT TYRE
VEE CROWN GEM 16×2.25″, 27TPI WB
REAR TYRE
VEE CROWN GEM 16×2.25″, 2TPI WB
HEADSET
1 1/8” CARTRIDGE BEARING, CONVENTIONAL
STEM
RITCHEY OS FORGED AL6061, 35MM REACH
BARS
480MM RITCHEY OS DOUBLE BUTTED AL6061, 18MM RISE
GRIPS
ER SOFT TOUCH MUSHROOM 100MM
SEAT POST
AL6061, 25.4MM x 195MM
SADDLE
BLACK FAUX NUBUCK
SEAT CLAMP
ER QR, 28.6MM
