Component
|
Details
|
|
Frame
|
Aluminium Superlite, Gravity Casting Technology, FSP 4-Link, Agile Comfort Geometry
|
|
Frame Sizes
|
S (27.5"), M, L, XL (29")
|
|
Colour
|
Blackline
|
|
Front Fork
|
RockShox Psylo Silver RC Air, tapered, 15x110mm, lockout, 140mm travel
|
|
Rear Shock
|
RockShox Deluxe Select R, rebound adjustment, Trunnion mount
|
|
Shock Size
|
205x60mm (29") / 185x55mm (27.5")
|
|
Shock Hardware
|
Top: 54mm Trunnion mount; bottom: 22.2x8mm
|
|
Motor
|
Bosch Performance Line CX, BDU38
|
|
Maximum Torque
|
120Nm
|
|
Remote/Display
|
Bosch Purion 200 with integrated display
|
|
Battery
|
Bosch PowerTube 800Wh
|
|
Charger
|
Bosch 2A
|
|
Rear Derailleur
|
SRAM Eagle 90 Transmission, 12-speed
|
|
Shifter
|
SRAM Eagle 70 Transmission
|
|
Cassette
|
SRAM XS-1270, 10–52T
|
|
Chain
|
SRAM Eagle 70 Transmission
|
|
Crankset
|
ACID MTB Hybrid Pro, 36T (27.5") / 34T (29")
|
|
Chain Guide
|
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
|
|
Brake System
|
Shimano BR-MT520 hydraulic disc brakes
|
|
Brake Rotors
|
203mm front / 203mm rear
|
|
Headset
|
ACROS AZF-1034 ICR, ZS 56mm top and bottom, X-Connect interface
|
|
Stem
|
CUBE Performance Stem E-MTB 35, FPI-Link
|
|
Handlebar
|
CUBE Rise Trail Bar 35
|
|
Grips
|
ACID Hybrid Perform
|
|
Wheelset
|
ACID PRO 30, 32/32 spokes, 15x110mm front / 12x148mm rear, tubeless ready
|
|
Tyres
|
Schwalbe Nobby Nic Performance, 2.6"
|
|
Saddle
|
ACID Venec EMTB Plus 145
|
|
Seatpost
|
CUBE Dropper Post, handlebar lever, internal cable routing, 31.6mm
|
|
Pedals
|
ACID PP MTB
|
|
Frame Features
|
Boost 148, UDH, integrated battery, internal cable routing, integrated seatclamp, kickstand/fender/carrier mounting points
|
|
Weight
|
26.8kg
|
