Frame:
Carbon HMF
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Range Extender Ready
Travel:
Front: 160mm / Rear: 155mm
Fork:
FOX 36 Float Rhythm Air Grip
3 modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 160mm travel
Rear Shock:
FOX NUDE 6T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Low Speed Adj. / Custom large Air volume / Reb. Adj.
Travel 155-100-Lockout / T185X55mm
Remote System:
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Drive Unit:
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Battery:
TQ Internal 360Wh
Display:
TQ HPR
Bluetooth / ANT+ / Dedicated Smartphone app
Charger:
TQ 100-240V-4A
Rear Derailleur:
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
Shifters:
Shimano Deore SL-M6100-IR / Rapidfire Plus
I-spec EV clamp
Crankset:
FSA Alloy crankset / 175mm / 34T
Chainguide:
e*thirteen / e*spec Slider
Chainring:
Scott custom spider / FSA 12Speed 34T chainring
Chain:
Shimano CN-M6100
Cassette:
Shimano CS-M6100 / 10-51 T
Brakes:
Shimano Deore M6120 4-Piston Disc
Rotor:
Shimano SM-RT64 CL / F&R 203mm
Handlebar:
Syncros Hixon 1.5 Alloy 7050
Size S & M 15mm rise / Size L & XL 25mm rise
back sweep 8� / 780mm
Syncros Endurance lock-on grips
Stem:
Syncros AM 1.5
Syncros Cable Integration System
4� rise / 7050 Alloy / 31.8mm / 1 1/8"
Seatpost:
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm
S size 140mm / M size 180mm / L & XL size 210mm
Seat:
Syncros Tofino 1.5 Regular
Titanium rails
Headset:
Syncros - Acros Angle adjust & Cable Routing HS System
Stainless / +-0.6� head angle adjustment
ZS56/28.6 � ZS56/40 MTB
Hub (Front):
Formula CL-811 / 15x110mm
Hub (Rear):
Formula CL-148M / 12x148mm
Spokes: Stainless Black 15G / 1.8mm
Rims:
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready
Front Tire:
Maxxis Dissector / 2.6" / 60TPI Foldable
Tubeless Ready / EXO 3C maxx Terra
Rear Tire:
Maxxis Dissector / 2.6" / 60TPI Foldable
Tubeless Ready / EXO 3C maxx Terra
Extras:
Syncros Fork Fender
Approx weight in KG:
19.5 (with tubes)
Approx weight in LBS:
42.99 (with tubes)
Max. System Weight:
128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
