Frame:
Spark Carbon HMF
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork:
FOX 34 Float Factory Air / Kashima FIT4
3-Modes with low Speed adj. / Kabolt 15x110mm axle / 44mm offset
Tapered steerer / Lockout / Reb. Adj.
130mm travel
Rear Shock:
FOX NUDE 5T Factory EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Kashima / Reb. Adj.
Travel 120-80-Lockout / T165X45mm
Remote System:
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Rear Derailleur:
SRAM X0 Eagle AXS Transmission 12 Speed
Wireless Electronic Shift System
Shifters:
SRAM GX Eagle AXS Rocker Controller
Crankset:
SRAM X0 Eagle Transmission
DUB / 55mm CL / 32T
BB-Set:
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain:
SRAM CN X0 Eagle Transmission
Cassette:
SRAM X0 Eagle XS 1295 Transmission 10-52
Brakes:
Shimano XT M8120 4 Piston Disc
Rotor:
Shimano RT-MT800 CL / F&R 180mm
Handlebar:
Syncros Fraser iC SL DC Carbon
0� rise / back sweep 8� / mini Rise / 760mm
Syncros Performance XC lock-on grips
Seatpost:
FOX Transfer Factory Dropper Post Kashima
31.6mm / S size 125mm / M size 140mm / L size 150mm / XL size 150mm
Seat:
Syncros Tofino 1.5 Regular
Titanium rails
Headset:
Syncros - Acros Angle adjust & Cable Routing HS System
Stainless
+-0.6� head angle adjustment
ZS56/28.6 � ZS56/40 MTB
Wheelset:
Syncros Silverton 1.0-30 6 Bolt
F: 15x110mm
R: 12x148mm
30mm Tubeless ready Carbon rim 28H
DT Swiss Ratchet Hubs / XD Driver
SRAM TyreWiz / Syncros SL Axle w/Removable Lever with 6mm Allen
T30 and T25 Tools
Front Tire:
Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Soft
Rear Tire:
Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Grip
Extras:
SRAM AXS Powerpack
Syncros Fork Fender
Accessories:
Syncros Eco Sealant
Transport Axle
Approx weight in KG:
11.4 (Tubeless setup)
Approx weight in LBS:
25.13 (Tubeless setup)
Max. System Weight:
128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
