Frame
Alloy Frame / Virtual 4 link kinematic VLK 27.5" and 29" compatible / geo adj. / Boost 148x12mm 140mm travel / Bosch Gen4 / Integr. removable Battery Tapered Headtube E2, Central Kickstand Mount Range Booster Ready
Fork
Marzocchi Z2 Air / eMTB+ Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer 44mm offset / Reb. Adj. / Lockout / 140mm travel
Rear Shox
X-Fusion NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 140-90-Lockout / 185x50mm
Remote command
SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 modes
Engine
Bosch Performance CX EU: 25kmh / INT: 20mph
Battery Charger
4A Charger
Rear Derailleur
SRAM NX Eagle / 12 Speed
Shift Levers
SRAM SX Eagle Single Click
Crankset
FSA CK-320 / 165mm / SRAM Eagle 34T DM / Steel
Sprocket
SRAM PG1210 / 11-50 T
Brakes
SRAM DB8 4 Piston Disc
Rotors
Centerline CL Rotors 200mm F&R
Handlebar
Syncros Hixon 2.0 Rise / Alloy 6061D.B. 20mm rise / 8° / 740mm Syncros Comfort lock-on grips
Stem
Syncros FL2.0 / 6061 Alloy L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.5 31.6mm / S size 100mm / M size 125mm / L size 150mm
Headset
Syncros ER2.0 Press Fit E2 / Tapered 1.5"-1 1/8" OD 52/62mm / ID 44/56mm
Front Hub
Formula CL-811 / 15x110mm
Rear Hub
Formula CL-148S / Boost 148x12mm
Rims
Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready
Front Tire
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead EXO Dual
Rear Tire
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead EXO Dual
Lights
Bosch Light Cable pre-installed F&R
Weight
23.8 (with tubes) kg
Weight Limit (System)
128 kg
