Liv 2024 Intrigue Advanced E+1 Elite

motor
Giant SyncDrive Pro2 Mg, 85Nm, Magnasium Casing, powered by Yamaha, PedalPlus 6-Sensor technology

controller
Giant RideControl Ergo3, grip integrated remote

display
Giant RideControl GO, frame integrated LED consoleOptional wireless ANT+ display

battery
Giant EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible

sizes
XS, S, M, L

colours
frame
Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system

fork
Fox 36 Factory E-Tuned, 29er, 150mm travel, 44mm offset, Grip2 VVC damper, Kabolt-X 110

shock
Fox Float X Factory, EVOL, 185x52.5mm Trunnion mount, custom tuned

handle bar
Giant Contact SLR Trail, carbon, 760mm (XS-S), 800mm (M-L)

grips
Liv Tactal Pro-E Single Lock-On Grips

stem
Giant Contact SLR Trail, integrated,40/45/50mm Reach, 7/9degree Sweep Adjust System

seatpost
Tranz-X Rad+ dropper, 30,9mm, 30mm travel adjustable (XS/S:90-125mm, M:120-150mm, L:140-170mm)

saddle
Liv Sylvia E+

pedals
-

shifters
SRAM AXS new NGD controller, wireless electronic shifting

front derailleur
rear derailleur
brakes
SRAM Code R, hydraulic disc, 220mm[F], 200mm[R]

brake levers
cassette
SRAM GX Eagle Transmission, 10-52T, 12-speed

chain
SRAM GX Eagle Transmission Flattop Chain, Powerlock

crankset
Praxis Performance Carbon e-crank arms (S/M:160, L/XL:165) SRAM Eagle Transmission E-MTB Chainring , Steel 36T

bottom bracket
rims
E-TRX Hookless Tubeless ready Carbon 29 [F] / 27.5 [R]30mm inner width

hubs
E-TRX MTB Alloy Hub, 6 Bolt, 110x15 [F] / 148x12 SRAM XD Drive Body Pawl Driver (Pawl 36x2 T) Thru-axle [R]

spokes
tires
Maxxis Minion DHF 29X2.50in Foldable, TLR, EXO [F]Maxxis Dissector 27.5x2.4in Foldable, TLR, EXO [R]

extras
Tubeless kit (liquid, valves, levers, manual, tool)Inner tube supplied

lighting
Optional:- Giant Recon series e-bike lights available and direct connectable

carrier
-

weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
