Frame
Alloy Frame / Virtual 4 link kinematic VLK
27.5" and 29" compatible / geo adj. / Boost 148x12mm
150mm travel / Bosch SmartSystem / Integr. removable Battery
1.5" Headtube
Central Kickstand Mount
Integr. Cable
Bosch PowerMore Ready
Travel
Front & Rear: 150mm
Fork
Marzocchi Z2 Air / eMTB+
Rail 3 / 3 modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 150mm travel
Rear Shock
X-Fusion NUDE Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 150-100-Lockout / 185x55mm
Remote System
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 modes
Drive Unit
Bosch Performance CX
EU: 25kmh / INT: 20mph
Battery
PowerTube 625Wh
Display
Bosch LED Remote & Intuvia 100
Charger
4A Charger
Rear Derailleur
SRAM NX Eagle / 12 Speed
Shifters
SRAM SX Eagle Single Click
Crankset
FSA CK-320 / 165mm / 34T
Chainring
SRAM Eagle 34T DM / Steel
Chain
SRAM SX Eagle
Cassette
SRAM PG1210 / 11-50T
Brakes
Shimano / BR-MT420 4 Piston
Rotor
Shimano / SM-RT64 CL 203mm
Handlebar
Syncros Hixon 2.0 Rise / Alloy 6061D.B.
20mm rise / 8° / 760mm
Syncros Comfort lock-on grips
H'stem
Syncros FL2.0 / 6061 Alloy
L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.5
31.6mm / S size 100mm / M size 125mm / L size 150mm / XL size 170mm
Seat
Syncros Capilano
Headset
Acros / 1.5"
ZS56 OD62 / BlockLock / integr. Cable
Hub (Front)
Formula CL-811 / 15x110mm
Hub (Rear)
Formula CL-148S / Boost 148x12mm
Spokes
Stainless Black
Rims
Syncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready
Front Tire
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead
EXO
Dual
Rear Tire
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead
EXO
Dual
Approx weight in KG
24.4 (with tubes)
Approx weight in LBS
53.79 (with tubes)
Max. System Weight
128kg
