FRAME |
Spark RC Carbon HMF, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline |
|
FORK |
FOX 32 Float Rhythm Grip 3, 3-Modes / Kabolt 15x110mm axle / 44mm offset / tapered steerer, Reb. Adj. / Lockout / 120mm travel |
|
REAR SHOCK |
FOX Float Custom EVOL Performace Trunnion, 3 modes / Lockout-Trail-Descend, DPS / Reb. Adj., Travel 120mm / T165X45mm |
|
REMOTE SYSTEM |
SCOTT TwinLoc 2 Technology, 3 Suspension modes |
|
REAR DERAILLEUR |
SRAM NX Eagle 12 Speed |
|
SHIFTERS |
SRAM NX Eagle Trigger |
|
BRAKES |
Shimano Deore M6100 Disc, Shimano SM-RT64 CL / 180/F and 160/R |
|
CRANKSET |
SRAM NX Eagle DUB, 55mm CL / 32T |
|
BB-SET |
SRAM DUB PF 92 MTB Wide / shell 41x92mm |
|
HANDLEBAR |
Syncros Fraser 2.0 XC Alloy 6061 D.B., Flat Bar / 8° / 740mm, Syncros Pro lock-on grips |
|
SEATPOST |
Syncros Duncan 2.0 / 10mm offset, 31.6x400mm |
|
SEAT |
Syncros Belcarra Regular 2.0, CRMO rails |
|
HUB (FRONT) |
Formula CL-811 / 15x110mm |
|
HUB (REAR) |
Formula CL-148S / 12x148mm, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools |
|
CHAIN |
SRAM CN NX Eagle |
|
CASSETTE |
SRAM SX-PG1210 / 11-50 T |
|
SPOKES |
Stainless Black 15G / 1.8mm |
|
RIMS |
Syncros X-30SE / 32H / 30mm, Tubeless ready |
|
TIRES |
Maxxis Rekon Race / 29x2.4” / 60TPI Foldable Bead, Tubeless Ready / EXO / Maxxis Rekon Race / 29x2.4” / 60TPI Foldable Bead, Tubeless Ready / EXO |
|
ACCESSORIES |
Transport Axle |
